Built on decades of clinical expertise in managing anesthetic challenges, the new multiparameter monitor empowers veterinary teams to perform procedures more efficiently, combining integrated safety features with an intuitive, user-friendly design.
Need Expert Advice?
Call us: +18333-46-8387
Flexible dual-slot modular design supporting IBP, EtCO2 (mainstream & sidestream), and anesthetic gas (AG) modules
Easy upgrades as your clinical needs grow
Advanced HiFi4 DSP co-processing core with operating frequencies up to 600 MHz
Configurable memory options: 128 / 256 / 512 MB DDR3, expandable up to 2 GB for stable, long-term performance
Available in 12.1” high-resolution touch LCD screen
Multiple display modes including large fonts, full/half screen views, and seven-channel waveform display
Standard parameters: ECG, NIBP, SpO2, RESP, and Temperature (2-TEMP)
Advanced analytics including ST segment and QRS analysis
Optional modules: IBP, EtCO2, AG, Nellcor® SpO2
Touchscreen interface and built-in recorder for enhanced workflow efficiency
VGA and HDMI expansion support
Seamless integration with central monitoring systems
Long-term data storage with easy review of patient history and trends
Integrated 4000 mAh lithium battery providing over 4 hours of backup
Low power consumption for extended product life and dependable operation
Stable, durable design optimized for clinics, hospitals, and mobile veterinary settings
| Parameter | Range | Accuracy |
|---|---|---|
| CO₂ | 0–15% | ± (0.2% + 5%) @ 0–10% ± (0.2% + 8%) @ 10–15% |
| Respiratory Rate (RR) | 3–150 bpm | ± 1 bpm |
| N₂O | 0–100% | ± (2% + 3% of reading) |
| Sevoflurane | 0–8% | ± (0.15% + 5% of reading) @ 0–5% ± (0.3% + 5% of reading) @ 5–8% |
| Isoflurane | 0–8% | ± (0.15% + 5% of reading) @ 0–5% ± (0.3% + 5% of reading) @ 5–8% |
| Enflurane | 0–8% | ± (0.15% + 5% of reading) @ 0–5% ± (0.3% + 5% of reading) @ 5–8% |
| Condition | Specification |
|---|---|
| Operating Temperature | 0 to 40 °C |
| Operating Atmospheric Pressure | 70 to 120 kPa |
| Operating Humidity | 10–95%, non-condensing |
| Storage Temperature | 20 to 70 °C |
| Storage Atmospheric Pressure | 50 to 120 kPa |
